System Overview:

FPSS 4800 series intelligent terminal is suitable for standalone mode, commercial power AMF mode, which can serve the functions of the automatic

start and stop of the unit, data measurement,alarm protection and cloud services. Intelligent terminal has built-in electronic governor, electronic injection

ECU interface, emergency stop switch and key switch. It is also equipped with

car-grade professional wire harness, electronic sensor, embedded installation

seal ring and airborne installation and shock absorption installation platform. Each intelligent terminal is calibrated according to customer requirements when

leaving the factory, which is a personalized customized product in the true sense. (Special note: the function is not fully compatible with each controller which

should be selected according to the customer.)


Functional features:


1. It has the functions of electric parameter waveform display, starting times

and running time record, alarm list, parameter setting beside the machine, monitoring environmental temperature and atmospheric pressure, etc;

2. Cloud cat board, GSM antenna, GPS antenna, mobile APP, customized web

page;

3. The system is equipped with sensors that we independently developed, including electromagnetic speed sensors, Euro-III water temperature and

Euro-III oil pressure sensors, which are the main sensors used in major engine

plants in China. 4. The wiring harnesses configured by the system have been included in the

models of mainstream models at home and abroad. They are manufactured

according to vehicle class standards. The main line is made of closed bellows, the outlet is equipped with tees, and the back end is protected by glass wool, which can ensure the quality and achieve the neat and beautiful effect of the

unit. 5. It has the functions of one-key repair curve record, real-time monitoring, sheet of bench test report record, historical fault curve record, etc;

6. It has three working modes: single, mains and parallel, and has functions of

mains self-starting, ATS cabinet, parallel quantity monitoring, closing quantity

monitoring, on-line total active power and reactive power display, etc;

7. In the aspect of municipal power supply, it can monitor three-phase mains

voltage, single-phase mains current or mains leakage current, mains frequency, mains phase, mains power, power factors, mains unbalanced voltage, switching

closing and closing state;

8. In the aspect of municipal power supply, the action thresholds such as voltage

fault, short circuit fault, overload fault, frequency fault, phase fault, power

failure, voltage unbalance and pulse width of MCB can be set;3

9. In terms of generator, it can monitor three-phase generation voltage line

voltage, phase voltage, three-phase generation current, generation frequency, generation phase, three-phase power generation power active power, reactive

power, apparent power, three-phase power generation power factor, zero

sequence current, unbalanced current, unbalanced current, generator operation

state, switch on and off state;

10. In terms of generator, the action thresholds such as power generation phase

fault, short circuit fault, overload fault, current fault, unbalanced current fault, power factor fault, magnetic flux leakage fault and GCB closing output pulse

width can be set;

11. In terms of generator, it can monitor the speed, water temperature, oil

pressure, oil temperature, fuel level, water tank level, air filter status, charging

generator, two-channels battery voltage, charging current, starting state, running

state, EFI CAN communication, starting output, preheating output, cooling fan

output, oil supply output, high and low speed output;

12. In terms of engine, it can set the speed alarm threshold, sensor fault action, charger fault action, timing start / stop action, inter unit communication, synchronous action, reverse power protection action, switch on and off action, start time, preheating time, cooling fan output conditions, power on / power off

shutdown time, power on shutdown output;

13. It has three kinds of fuel system: mechanical control, electric control and

electronic injection;

14.Three channels of configurable digital Inputs, one channel of configurable

analogue Input, four channels of configurable digital outputs, one channel of

start current sensing, one channel of rack position sensing;

15. The features of cloud services are compatible, such as parallel function, display of historical records (running time, starting times, alarm list), running

condition statistics of web page, RS485 communication, two-channels CAN

communication and WiFi function;4

16. The system parameters can be calibrated according to customer requirements, or through the host computer software, and it supports remote data calibration

(cloud cat version).

17. Quality standard: the protection grade meets IP55, the ambient temperature

meets - 30 ℃ ~ 70 ℃, and other performance indexes meet the national standard

of control of AC generator set driven by reciprocating internal combustion

engine.
